L 510 x W 460mm - L 50 x W 50mm Note : Available in lengths up to L950mm as an option.
Applicable Components
03015mm to W55 x L100mm (For parts sizes larger the width 45mm, recognition of parts is divided into sections.), Height 15mm or less. Note : A multi camera (option) is required for part heights exceeding 6.5mm or part sizes exceeding 12mm
Mounting Capability
HM head (10 nozzle) specification : 46,000CPH (under optimum conditions as defined by Yamaha Motor) HM 5 head (5 nozzle) specification : 31,000CPH (under optimum conditions as defined by Yamaha Motor)
Mounting Accuracy (Under Optimum Conditions As Defined By Yamaha Motor When Standard Evaluation Materials Are Used)
+/-0.035mm (+/-0.025mm) Cpk 1.0 (3σ)
Number Of Component Types
Fixed plate : Max. 96 types (conversion for 8mm tape feeder) Note 1 Tray : 15 types (maximum when equipped with sATS15, JEDEC)
Power Supply
3-Phase AC 200/208/220/240/380/400/416V +/-10% 50/60Hz
Air Supply Source
0.45MPa or more, in clean, dry state
External Dimension
L1,254 x W1,440 x H1,445mm
Weight
Approx. 1,270kg
Note 1 : Please consult our sales representative if you need feeder carriage specifications. Specifications and appearance are subject to change without prior notice.
Specifications and appearance are subject to change without prior notice.
YAMAHA Compact High-Speed Mounter YSM10
