YAMAHA pick and place machine YSM20R is a high-performance, modular surface mount technology (SMT) placement machine engineered for high-speed, high-mix production environments. It represents a significant advancement in the Yamaha line, combining blistering speed with remarkable accuracy and flexibility to meet the demanding requirements of modern electronics manufacturing.

At its core, the YSM20R boasts a revolutionary twin-beam, dual-arm gantry structure. This innovative design allows its two independent mounting heads to operate simultaneously within the same workspace, dramatically optimizing movement patterns and minimizing non-productive wait time. Each head is capable of mounting a wide range of components, from miniature 01005 (0.4 x 0.2mm) chips up to large connectors or odd-form components measuring 90 x 90mm. This eliminates the need for a separate dedicated machine for larger parts, streamlining the production line.

A key feature is its impressive placement rate of up to 120,000 components per hour (CPH) under optimal conditions. This speed is complemented by its advanced vision system, which ensures precision and reliable recognition of even the most challenging components. Furthermore, the machine supports reel-on-reel and tray-on-reel functionality, significantly extending unmanned operation time by reducing the frequency of material replenishment. With its robust construction, user-friendly YSU software, and emphasis on maximizing throughput while minimizing changeover times, the YSM20R establishes itself as a versatile and powerful solution for manufacturers seeking to enhance efficiency and capacity in their SMT assembly processes.

YAMAHA pick and place machine YSM20R High-Speed Modular Mounter - Technical Specifications

Category	Parameter	Specification	Notes / Units
General Model	Machine Name	Yamaha YSM20R
	Machine Type	Modular High-Speed Mounteer	For SMT Lines
Placement Performance	Max. Theoretical Speed	120,000	CPH (Components Per Hour)
	Practical Speed	~ 90,000	CPH (Depends on configuration)
	Placement Accuracy	±20μm @ 3σ / ±25μm @ 4σ
	Minimum Component Size	0.4 x 0.2 mm (01005)
	Maximum Component Size	90 x 90 mm	From Tray. Height: ≤ 15mm
	Maximum Component Weight	150	grams
Mechanical Structure	Mounting Head Configuration	Twin-Beam, Dual Independent Heads
	Head Type	Rotary Multi-Nozzle Heads	8 or 12 Nozzles, Auto-changing
	Drive System	Linear Motor Drive	For high speed & precision
Vision System	Vision Camera	High-Resolution Downward Camera	For component alignment
	Lighting	Integrated Multi-LED Ring Illuminator	Programmable lighting modes
	Recognition Capabilities	Chips, QFP, QFN, BGA, LGA, Connectors, Odd-Form
Feeder System	Maximum Feeder Capacity	Up to 108	Slots (for 8mm tape)
	Supported Tape Widths	8mm, 12mm, 16mm, 24mm, 32mm, 44mm, 56mm
	Tray Feeder Capacity	Up to 24	Optional Double Stack available
	Bulk Feeder	Optional
Board Handling	Maximum Board Size	L 510 x W 460 mm
	Minimum Board Size	L 50 x W 50 mm
	Board Thickness Range	0.4 - 5.0	mm
	Conveyor Direction	Left to Right
	Conveyor Height	900 ±20	mm
Utility Requirements	Power Supply	200V AC	3-Phase
	Air Pressure Source	0.5 MPa or greater
	Air Consumption	Approx. 200	NL/min
	Machine Weight	~ 3,500	kg (varies by configuration)
Software & Control	Operating Software	YSU (Yamaha SMT Software)
