Hanwha-Mounter-SM481Plus

SM series models are the best selling products and have been proven by many customers worldwide.

Alignment
Fly Camera + Fix Camera (Option)

Spindle & Speed
1 Gantry * 10 Spindle / 40,000 CPH

Accuracy
±40μm@±3σ (Chip) / ±30μm@±3σ(QFP)

Component Range
Fly: 0402 ~ □16mm / Fix: ~□55mm, L75mm Connector

Dimension
L 1,650 x D 1,680 x H 2,090

Download

Product Details
Parameter
Video

Hanwha-Mounter-SM481Plus

SM series models are the best selling products and have been proven by many customers worldwide.

Specification

			SM471PLUS	SM481PLUS	SM482PLUS	SM485
Alignment			Fly Camera	Fly Camera	Fly Camera	Fly Camera
				+ Fix Camera (Option)	+ Fix Camera	+ Fix Camera
The Number of Spindles			10 Spindes x 2 Gantry	10 Spindle x 1 Gantry	6 Spindle x 1 Gantry	4 +1Spindle x 1 Gantry
Placement Speed			78,000CPH (Optimum)	40,000 CPH (Optimum)	30,000 CPH (Optimum)	22,000 CPH (Optimum)
Placement	Chip		±40μm@±3σ
Accuracy	QFP		±50μm@±3σ	±30μm@±3σ
Component Range	*Fly Camera	Chip	0402 ~ □14mm	0402 ~ □16mm	0603 ~ □22mm (*** 0402 ~ □14mm)	0402 ~ □21 mm
		IC, Connector
		BGA, CSP
	*Fix Camera	C, Connector	-	□16mm ~□42mm (Standard) □42mm ~□55mm (MFOV) L55mm ~ L75mm Connector (MFOV)		□16mm ~□42mm (Standard) □42mm ~□55mm (MFOV) L75mm ~ L150mm Connector (MFOV)
		BGA, CSP

	Max. Height		12 mm	10 mm (Fly)	12 mm (Fly)	15 mm (Fly)
				15 mm (Fix)	25 mm (Fix)	26 mm (Fix)
PCB Size (mm)	Min.		L50 x W40
	Max.	Single Lane	~ L510 x W460~ L610 x W460 (Option)	~ L460 x W400 ~ L510 x W460 (Option) ~ L610 x W510 (Option) ~ Max. L1,500 x W460 (Option)	~ L460 x W400 ~ L510 x W460 (Option) ~ L610 x W510 (Option) ~ Max. L1,200 x W510 (Option)	~ L460 x W400 ~ Max. L740 x W460 (Option)



		Dual Lane	~ L510 x W460 ~ L610 x W460 (Option)	-	-	-

	PCB Thickness		0.38 ~ 4.2
Feeder Capacity (8mm standard)			120ea/112ea (Docking Cart)

Utility	power		AC200 / 208 / 220 / 240 / 380 / 415V (50/60Hz, 3Phase)
			Max. 5.0kVA	Max. 3.5kVA	Max. 3.5kVA	Max. 3.5kVA
	Air Consumption		0.5 ~ 0.7MPa (5.0 ~ 7.0kgf/cm2)
			350N&/min 50N&min(Vacuum Pump）	160N&/min 50N&min(Vacuum Pump）	180N&/min 50N&min(Vacuum Pump）	180N&/min 50N&min(Vacuum Pump）

Mass (kg)			Approx. 1,730	Approx. 1,655	Approx. 1,575	Approx. 1600
External Dimension (mm)			L1,650 x D1,690 x H1,485	L1,650 x D1,680 x H1,530	L1,650 x D1,680 x H1,530	L1,650 x D1,680 x H1,530
