Hanwha Decan S2 Advanced Chip Shooter

The DECAN series models can handle a wide range of components and maximize productivity with various PCB transfer systems.

1, Secures the applicability to components and conveyor flexibility.

2, Reduces production time by optimizing the motion sequence.

3, Reinforces odd-shape component recognition by applying 3D lighting system.

Hanwha Decan S2 Advanced Chip Shooter

Specification

Model	DECAN S2	DECAN F2	DECAN L2
# of Spindles	2 Gantry x 10 Spidles/Head	2 Gantry x 10 Sp idles/Head	2 Gantry x 6 Spidles/Head
Placement Speed (Under optimum condition of as defined by Hanwha Techwin.)	92,000 CPH (Optimum)	80,000 CPH (Optimum)	56,000CPH (Flying Vision, Optimum) • 0.14 seconds/component (Flying Vision, SOIC 0.5P) • 0.55 seconds/component (Upward Vision, QFPl 00 0.5P)
Vision	Flying Vision	Flying Vision Stage Vision(Option)
Placement Accuracy	±28μm Cpk.: 1 .0 (03015 chip) ±25μm Cpk.: 1.0 (IC)	±40μm Cpk.: 1.0 (0402 (01005 inch) chip) ±30μm Cpk.: 1 .0 (IC, Stage Vision)
Component Range	03015 - Max. ossmm (H15mm)	0402 (01005 inch)Max. o 55mm (Hl 5mm)	0402 (01005 inch)- Max. o 55mm, L75mm (H25mm)
PCB Size	50 x 40 -510x 460mm (Standard) -610 x460mm (Option), -740 x 460mm (Option) -810 x460mm (Option), -1,200 x 460mm (Option)
Conveyor Configurations	Standard : 1-2-1 Option: 1-2-2/2-2-2/2-2-1/1-1-1 Factory Option: Single Conveyor (Jedec Tray 2ea)
Feeder Capacity	120ea (8mm)
Power	Voltage : 3 phase AC200/208/220/240/380/41 SV ± 10% Frequency : S0/60Hz Power Consumption : Max. 5.0kVA
Air Consumption	50NI/min
Weight	About 1,800kg
External Dimensions (mm)	1,430(l) x 1,740(D) x 1,48S(H)
