SMT Buffer / NG Buffer

Cooling Buffer: Essential Thermal Management

The Cooling Buffer provides controlled temperature reduction for PCBs after reflow soldering. Its key features include gradual cooling to prevent thermal stress, ESD-safe material construction, adjustable conveyor speed for different thermal profiles, and compact modular design. This system ensures board stability before inspection while maintaining continuous production flow.

Cooling Buffer: Essential Thermal Management for SMT Assembly

The Cooling Buffer is a specialized conveyor system designed to provide controlled cooling for PCBs after the reflow soldering process. It ensures proper thermal management by gradually reducing board temperature before components reach subsequent handling or inspection stations.

Key Features & Functions:

Gradual Temperature Reduction: Prevents thermal shock to components and PCB substrates

Adjustable Cooling Rate: Variable speed control manages dwell time for different board specifications

Static Dissipation: Built-in ESD protection throughout the cooling path

entle Board Handling: Smooth transportation prevents component displacement during fragile post-reflow phase

Process Integration: Seamless SMEMA communication with upstream reflow ovens and downstream equipment

Critical Benefits:

Quality Assurance: Eliminates thermal stress that could cause microcracks or latent defects

Inspection Readiness: Brings boards to optimal temperature for accurate AOI and testing

Line Synchronization: Buffers boards between reflow and next processes, balancing line flow

This thermal management solution protects product reliability while maintaining production rhythm - making it indispensable for quality-conscious SMT lines.

FAQ about Cooling Buffer

Qustion : How many locations are there for storing the PCB?

AcceptedAnswer : 15pcs (pitch 30mm) or customized

Qustion : What is the positioning accuracy?

AcceptedAnswer ：Our products can achieve a positioning accuracy of ±0.1mm.

Qustion : What is the ideal temperature reduction rate?

AcceptedAnswer :About 15 seconds

Qustion : How does the cooling buffer integrate with my existing conveyor system?

AcceptedAnswer :PCBs are transported via guide rails, and data communication is achieved using SMEMA data cables.

Qustion : What is the maximum board size ?

AcceptedAnswer ：PCB size:150*150mm-1200mm*350mm

Qustion : How does it integrate with our existing conveyor line?

AcceptedAnswer :Turning conveyors are typically used in SMT line with conveyors or shuttles.

Qustion : What is the delivery time?

AcceptedAnswer :30 days。

Qustion :What shipping method will be used for the shipment?

AcceptedAnswer :Supports sea and air freight.
