Product Overview

The TX5600 Electric PCBA Cleaning Machine is a high-efficiency automated cleaning solution designed for PCBA (Printed Circuit Board Assembly) contamination removal after soldering processes.
Using an electric driven wash system, TX5600 delivers consistent and repeatable cleaning performance, ensuring flux residues, particles, and solder dross are reliably removed from both SMT and through-hole assemblies.

This machine is ideal for factories pursuing improved reliability, reduced rework, and stable quality in electronics production.

-----------------------------------------------------------------------------------------------------------------------------------------

Why PCBA Cleaning Matters

After soldering—whether SMT reflow or wave solder—residual flux, solder paste components, and particles often remain on the board surface. If not properly removed, these residues can cause:

• Reduced insulation resistance

• Increased corrosion risk

• Electrical leakage or short circuit

• Field failures and warranty issues

Automatic PCBA cleaning improves product reliability and reduces costly rework or field defects.

------------------------------------------------------------------------------------------------------------------------------------------

Core Features

✔ Electric Driven Cleaning Mechanism
Stable, controllable cleaning force with precise motion control for consistent wash quality.

✔ Multi-Stage Cleaning Process
Separate stages for wash, rinse, and dry to ensure contaminants are fully removed.

✔ Adjustable Wash Parameters
Cleaning time, spray pressure, and conveyor speed can be adjusted for different board sizes and contamination levels.

✔ Intelligent Control System
PLC control with touchscreen interface for easy operation and recipe management.

✔ Efficient Rinse & Dry System
Integrated rinse and drying processes reduce residual moisture and speed throughput.

--------------------------------------------------------------------------------------------------------------------------------------------

Typical Application Scenarios

TX5600 is widely used in:

• SMT assembly post-reflow cleaning

• Through-hole assembly cleaning after wave soldering

• Hybrid PCBA production lines

• Electronics manufacturing requiring high reliability

• Connector and BGA area cleaning

Whether for consumer electronics, automotive, or industrial boards, proper cleaning helps improve long-term performance.

--------------------------------------------------------------------------------------------------------------------------------------------

Integration Into Your Production Line

The TX5600 can be integrated as:

1. Post-solder cleaning station
   – Positioned after reflow and/or wave solder ovens

2. Pre-test cleaning
   – Before functional or ICT testing

3. Batch cleaning
   – Boards queued and processed continuously

4. Inline production cell
   – Integrated with conveyors for automatic flow

Smooth integration improves line efficiency and reduces manual handling.

--------------------------------------------------------------------------------------------------------------------------------------------

Advantages Over Manual Cleaning

Automatic cleaning delivers repeatable quality and reduces operator dependence.

-----------------------------------------------------------------------------------------------------------------------------------------------

Why Choose TX5600 from Thomao

At Thomao, we focus on solving real production problems, not just selling machines.

With TX5600, you gain:

• Engineering support for setting optimal cleaning recipes

• Integration advice for multi-process production lines

• Training for operators and maintenance teams

• Spare parts and long-term service support

👉 Not sure if PCBA cleaning is right for your line? Contact Thomao for personalized recommendations.

-------------------------------------------------------------------------------------------------------------------------------------------------
